TCI Tricone Drill Bits

Engineered for Extreme Durability

When drilling time is money, you can't afford premature failure. ValcoBlue's TCI Tricone Bits are built in the USA to withstand the most abrasive environments on earth. We use premium microwave-sintered tungsten carbide inserts and advanced bearing seal technology to deliver superior footage per run. Stop tripping for bit changes—keep turning to the right with confidence.

Maximize ROP: Aggressive cutting structures for medium to hard rock
Premium Metallurgy: High-grade tungsten carbide resists cracking and wear
Advanced Protection: O-ring sealed bearings for extended downhole life
Hydraulic Efficiency: Optimized jet nozzle placement for superior hole cleaning
Proven Reliability: 100% Made in America quality control

TCI Bits

Designed for medium to hard formations with IADC codes 4XX-8XX.

Series 4: Medium formations
Series 5: Medium-soft to medium formations
Series 6: Medium to medium-hard formations
Series 7: Hard and abrasive formations

Options

Tungsten carbide insert cutting structure
Journal or roller bearing systems
Optimized hydraulics and nozzle configurations
Sealed bearing and gauge protection packages

Technical Specifications

Parameter	Specification
Insert Material	Premium-grade tungsten carbide
Bit Body	Forged American alloy steel
Bearing Type	Sealed journal or roller bearings
Diameter Range	3 7/8" to 20"
IADC Codes	417-837
Formation Hardness	Medium to hard

TCI Tricone Series

ValcoTCI 400 Series

Designed for medium with balanced cutting and durability properties.

IADC Codes: 417-447
Typical Applications: Shale, Limestone, dolomite

ValcoTCI 500 Series

Designed for medium-soft to medium formations with balanced cutting and durability properties.

IADC Codes: 517-547
Typical Applications: Limestone, dolomite

ValcoTCI 600 Series

Engineered for medium to medium-hard formations requiring enhanced insert durability.

IADC Codes: 617-637
Typical Applications: Hard limestone, sandstone

ValcoTCI 700 Series

Specialized for hard and abrasive formations with premium wear-resistant inserts.

IADC Codes: 717-737
Typical Applications: Hard sandstone, granite

TCI Datasheets

Key Features

Premium Tungsten Carbide Inserts
Specially formulated carbide grades optimized for specific formation hardness ranges.
Advanced Bearing Systems
Sealed journal bearings with proprietary lubricant reservoirs for extended downhole life.
Optimized Hydraulics
Strategically positioned nozzles for maximum cuttings evacuation and bit cooling.
Engineered Insert Placement
Computer-optimized insert patterns for balanced cutting action and reduced vibration.

Applications

Oil & Gas Drilling
Reliable performance in vertical, directional, and horizontal wells.
Geothermal Drilling
Durability in high-temperature environments with hard basement rock formations.
Mining & Exploration
Efficient large-diameter drilling for blast holes and exploration wells.
Water Well Drilling
Cost-effective penetration through mixed and abrasive formations.

Custom Solutions Made in the USA

Every drilling project has unique challenges. Our engineering team specializes in developing custom TCI tricone bits tailored to your specific formation and operational requirements, all manufactured in our U.S. facilities.

Contact Our Experts
